Portable Dental Units
Super-Port
17kg
Suction 220 L/min
Turbine / Air polisher possible
Full performance
Plug-and-Play
All-in-One
The champion in all categories
SUPER-PORT is the most complete and comfortable portable treatment unit in the world. The self-suf- ficient SUPER-PORT combines a complete dental treatment unit including compressor and suction machine in a light, 17 kg case. SUPER-PORT is equipped ex works with an electric motor with LED light, an electric scaler with LED light, an instrument hose for your turbine/air polisher and a suction (220 l/ min!). All the instruments as well as the suction have the same power as a fixed installation treatment unit and can be used in continuous operation. The preinstalled electrical micro-motor with LED light has a control unit with 30 freely selectable programs (incl. endo). The speed, torque and the selec ted contra-angle can be freely set and saved. You can also use your turbine or air polisher in addition to the motor with full power in continuous operation. The high capacity of SUPER-PORT is rounded off by a highly efficient patent-pending suction (220 l/min!). The smart design of SUPER-PORT enables ef ficient assembly and disassembly and together with DENTA-TROLLEY a comfortable transportation.
Features
- 1 Three-way syringe (air/water/spray) with sterilisable tips (hose and tips detachable)
- 1 Electric micromotor with LED light (0-40,000) and 30 programs
- 1 Electric scaler with LED light
- 1 Instrument hose with LED light (for turbine/air-flow)
- Instrument hoses detachable
- Spray adjustment regulators for each instrument
- Integrated spray water system for syringe and instruments (check valve prevents the back flow of water)
- 1 Spray water tank: 0.75 litre
- 1 High-performance suction hose 220 l/min. Continuously adjustable. With the patent-pending BPR Swiss technology. Adapter for saliva ejector tips and oral-dry-cup
- 1 Suction fluid container: 1 litre (automatic overflow protection)
- Pressure regulator-filter
- Sturdy, air- and water-tight plastic construction, will not scratch, dent or corrode
- Detachable front cover
- Disc type foot control
- Integrated silent compressor – oil-free
- DENTA-TROLLEY with drawers for instruments and consumables
Technical Data
- Handpiece pressure: 5.0-7.0 bar
- Each instrument is individually adjustable
- Weight SUPER-PORT: 17.0 kg
- Weight DENTA-TROLLEY: 8 kg (for consumables/instruments)
- Dimensions SUPER-PORT: 380 x 205 x 530 mm
- Dimensions DENTA-TROLLEY: 410 x 400 x 550 mm
Warranty: 2 years
Options: Turbine, air polisher, additional electrical motor, contra-angles, DENTA-CASE etc.
Comparison
Smart-Port Premium
12 kg
Full performance
Denta-trolley
Suction 220 L/min
Plug-and-Play
Full performance
All-in-One
Comfort made easy
The cleverly designed SMART-PORT Premium is the perfect device for the mobile dentist. In an 12-kilogram light case, SMART-PORT Premium combines the most important functions and operations of a dental treatment unit and leaves nothing to be desired: Convenient transport, easy setup and dismantling and full performance in continuous operation. The integrated electric micromotor with LED light features a control unit with 30 selectable programs. Speed, torque, and the selected contra-angle can be freely adjusted and saved. Through the use of various contra-angles, speeds of between 0-200,000 rpm can be achieved. Both the electric motor and the integrated electric scaler with LED light work at their full capacity. The high performance of SMART-PORT Premium is rounded off by a highly efficient patent-pending suction (220 l/min!). The clever design allows for quick and easy assembly and disassembly of the unit. Additionally, the SMART-PORT Premium impresses with its quiet oil-free compressor.
Features
- 1 Three-way syringe (air/water/spray) with sterilisable tips (hose and tips detachable)
- 1 Electric micromotor with LED light and 30 programs (0-40,000)
- 1 Electric scaler with LED light
- Instrument hoses detachable
- Spray adjustment regulators for each instrument
- Integrated spray water system for syringe and instruments (check valve prevents the back flow of water)
- 1 Spray water tank: 0.75 litre
- 1 High-performance suction hose 220 l/min. Continuously adjustable. With the patent-pending BPR Swiss technology. Adapter for saliva ejector tips and oral-dry-cup
- 1 Suction fluid container: 1 litre (automatic overflow protection)
- Pressure regulator-filter
- Sturdy, air- and water-tight plastic construction, will not scratch, dent or corrode
- Detachable front cover
- Disc type foot control
- Integrated silent compressor – oil-free: Max. Pressure: 4 bar;
- Integrated aspirator with the patent-pending BPR Swiss technology
- Accessories: Including DENTA-TROLLEY with drawers for instruments and consumables
Technical Data
- Handpiece pressure: 3.0-4.0 bar
- Each instrument is individually adjustable
- Weight SMART-PORT Premium: 12.0 kg
- Weight DENTA-TROLLEY: 8 kg (for consumables/instruments)
- Dimensions: 380 x 205 x 530 mm
Warranty: 2 years
Options: Polymerisation lamp, contra-angles etc.
Video
Comparison
Smart-Port
12 kg
Suction 220 L/min
Denta-trolley
Full performance
Plug-and-Play
All-in-One
The Lightness of Being
The cleverly designed SMART-PORT integrates the most important functions and operations of a dental treatment unit in a single 12-kilogram case. To activate the SMART-PORT simply insert the power plug into an outlet. The integrated electric micromotor with LED light and the integrated electric scaler with LED light both have full performance capability. Through the use of various contra-angles, speeds of between 0-200,000 rpm can be achieved. The high performance of the SMART-PORT is complemented by a highly efficient patent-pending suction (220 l/min!). In addition to its unparalleled performance, the SMART-PORT offers all-around convenience. The clever design allows for quick and easy assembly and disassembly of the unit. In addition, the SMART PORT has a remarkably quiet oil-free compressor and convenient externally removable instrument hoses.
Features
- 1 Three-way syringe (air/water/spray) with sterilisable tips (hose and tips detachable)
- 1 Electric micromotor with LED light (0-40,000)
- 1 Electric scaler with LED light
- Instrument hoses detachable
- Spray adjustment regulators for each instrument
- Integrated spray water system for syringe and instruments (check valve prevents the back flow of water)
- 1 Spray water tank: 0.75 litre
- 1 High-performance suction hose 220 l/min. Continuously adjustable. With the patent-pending BPR Swiss technology. Adapter for saliva ejector tips and oral-dry-cup
- 1 Suction fluid container: 1 litre (automatic overflow protection)
- Pressure regulator-filter
- Sturdy, air- and water-tight plastic construction, will not scratch, dent or corrode
- Detachable front cover
- Disc type foot control
- Integrated silent compressor – oil-free: Max. Pressure: 4 bar;
- Integrated aspirator with the patentpending BPR Swiss technology
- Accessories: Including DENTA-TROLLEY with drawers for instruments and consumables
Technical Data
- Handpiece pressure: 3.0-4.0 bar
- Each instrument is individually adjustable
- Weight SMART-PORT: 12.0 kg
- Weight DENTA-TROLLEY: 8 kg (for consumables/instruments)
- Dimensions: 380 x 205 x 530 mm
Warranty: 2 years
Options: Polymerisation lamp, contra-angles, DENTA-CASE etc.
Video
Comparison
Denta-Pro
Continuous operation
Full performance
2.3 kg
Denta-Bag
Plug-and-Play
Performance made easy
The DENTA-PRO is your reliable, efficient and user-friendly partner in mobile dentistry. To activate the DENTA-PRO simply insert the power plug into an outlet. Despite the very low weight of 2.3 kg the instruments of the DENTA-PRO have complete performance and can be used in continuous operation. In addition to the reliability and performance, the automatic instrument recognition and the internal spray additionally increase the efficiency of the DENTA-PRO.
Features
- 1 Electric micromotor with LED light
- 0-40Â 000 rpm (with red contra-angle to 200Â 000 rpm)
- Internal spray
- Clockwise and anticlockwise rotation
- 1 Electric scaler with LED light EMS
- Automatic instrument recognition
- Continuously regulation of the motor and scaler with rotary knob
- Continuously regulation of the water quantity with rotary knob
- 1 Spray water tank: 0.75 litres
- Water filter
- 1 foot control
Technical Data
- Each instrument is individually adjustable
- Weight: 2.3 kg (weight including DENTA-BAG and foot pedal: 3.6 kg)
- Dimensions DENTA-PRO: 275mm × 130mm × 130mm
- Dimensions DENTA-BAG carrying bag: 300mm × 275mm × 275mm
Warranty: 2 years
Options: Contra-angles, MINIMAX-VAC, DENTATROLLEY, DENTA-CASE etc.
Comparison
Minimax-Vac
Continuous operation
3.9 kg
Full performance
Suction 220 L/min
Denta-bag
Plug-and-Play
High-tech in miniature
The MINIMAX-VAC sets new standards in portable plug-and-play suction units. To start the MINIMAX-VAC it only needs to be plugged into mains power. With a weight of only 3.9 kilograms (!), the MINIMAX-VAC, with over 220 l / min (!), achieves a comparable suction to a permanently installed treatment unit in a dental office. The suction can be seamlessly regulateted any time. Due to this pioneering key data MINIMAX-VAC can be used in many areas such as mobile dentistry, in the dental office, or in numerous other areas of medicine.
Features
- 1 High-performance suction hose 220 l/min
- 1 rotary knob for continuously variable regulation
- Patent-pending BPR Swiss technology
- With adapter for saliva ejector tips and oral-drycup
- 1 Suction fluid container: 1 litre (automatic overflow protection)
- 1 DENTA-BAG carrying bag
Technical Data
- Weight: 3.9 kg (weight including DENTA-BAG 4.5 kg)
- Dimensions MINIMAX-VAC: 190mm × 140mm × 285mm
- Dimensions DENTA-BAG carrying bag: 300mm × 275mm × 275mm
Warranty: 2 years
Options: DENTA-PRO, DENTA-TROLLEY, DENTA-CASE etc.
Comparison
Combi-Port Premium
All-in-One
Plug-and-Play
Silent Oil-free compressor
Full perfomance
Continuous operation
Suction 200 L/min
Mobile Comfort
The COMBI-PORT PREMIUM offers you maximum performance and optimal comfort for treatments outside your dental clinic. All optional instruments can be operated at full efficiency in continuous use, such as micromotors, turbines, scalers or even air flows. The high-performance COMBI-PORT PREMIUM is rounded off by its highly efficient aspirator of 220 l/min (patent-pending BPR Swiss technology). The suction capacity is continuously adjustable. Compactly fitted into a trolley, after work the COMBI-PORT PREMIUM can easily be collapsed and wheeled to the next workplace like a suitcase. The high-performance COMBI-PORT PREMIUM compressor not only enables working throughout the day without interruption, but is also distinguished by its remarkably quiet operation (48 dB!).
Features
- 1 Three-way syringe (air/water/spray) with sterilisable tips
- Integrated spray water system for syringe and instruments (check valve prevents the back flow of water)
- 3 instrument hoses
- Spray adjustment regulators for each instrument
- 1 Spray water tank: 0.75 litre
- 1 High-performance suction hose 220 l/min. Continuously adjustable. Patent-pending BPR Swiss technology. Adapter for saliva ejector tips and oral-dry-cup
- 1 Suction fluid container: 1 litre (automatic overflow protection)
- Pressure regulator-filter with hose (6 x 4 mm) to air source
- Sturdy, air- and water-tight plastic construction, will not scratch, dent or corrode
- Detachable front cover
- Disc type foot control
- Integrated compressor Denta-Comp Premium – oil-free: Capacity 75 l/min at 4 bar; Max. Pressure: 8 bar; Sound pressure level: 48 dB; Compressed air tank: 4 litres
- Integrated aspirator with the patent-pending BPR Swiss technology
Technical Data
- Air consumption instruments: 35-55 l/min
- Handpiece pressure: 2.5-3.5 bar
- Each instrument is individually adjustable
- Dimensions treatment position: 540mm × 530mm × 1070mm
- Dimensions transport position: 540mm × 530mm × 760mm
- Weight: 47 kg
- Case unit dimensions: 370mm × 190mm × 500mm
- Case unit weight: 8 kg
Warranty: 2 years
Options: Light for instruments, electric scaler, polymerisation lamp, electric micromotor, air motor, turbine, contra-angles, arm with tray, arm with lamp, DENTA-TROLLEY, DENTA-CASE etc.
Comparison
Easy-Port 303
Plug-and-Play
Freely selectable configuration
Full perfomance
Continuous operation
Suction 220 L/min
Portable, flexible and reliable
It is impossible for your patients to visit you at your dental clinic? With the EASY-PORT 303, you can visit your patients at home or in nursing homes and provide them with optimal treatment. The EASY-PORT 303 treatment unit has all the functions and features needed for professional dental treatment, and offers you maximum flexibility. Thanks to the high-performance DENTA-COMP EASY compressor you can work all day without interruptions, at any time and at full efficiency. EASY-PORT 303‘s high capacity is complemented by the highly efficient patent-pending suction (220 l/min!).
Features
- 1 Three-way syringe (air/water/spray) with sterilisable tips
- Integrated spray water system for syringe and instruments (check valve prevents the back flow of water)
- 3 instrument hoses
- Spray adjustment regulators for each instrument
- 1 Spray water tank: 0.75 litre
- High-performance suction hose 220 l/min. Continuously adjustable. Patent-pending BPR Swiss technology. Adapter for saliva ejector tips and oral-dry-cup
- 1 Suction fluid container: 1 litre (automatic overflow protection)
- Pressure regulator-filter with hose (6 x 4 mm) to air source
- Sturdy, air- and water-tight plastic construction, will not scratch, dent or corrode
- Detachable front cover
- Disc type foot control
- Denta-Comp Easy compressor - oil free: Capacity 65 l/min at 3 bar; Max pressure: 7 bar; Sound pressure level: 56 dB; Compressed air tank: 3.5 litres
- Integrated aspirator with the patent-pending BPR Swiss technology
Technical Data
- Air consumption instruments: 35-55 l/min
- Handpiece pressure: 2.5-3.5 bar
- Each instrument is individually adjustable
- Case unit weight: 8.0 kg
- Case unit dimensions: 470 x 340 x 190 mm
- Compressor weight: 15 kg
- Compressor dimensions: 345 x 270 x 470 mm
Warranty: 2 years
Options: Light for instruments, electric scaler, polymerisation lamp, electric micromotor, air motor, turbine, contra-angles, DENTA-TROLLEY, DENTA-CASE etc.
Comparison
Denta-Port 303
8 kg
Freely selectable configuration
Full perfomance
Continuous operation
Suction 220 L/min
The father of all portable dental units
The unmatched flexibility and quality of DENTA-PORT 303 are at the root of all BPR Swiss portable treatment units. It can be equipped with all the instruments of your choice. Each instrument operates with full efficiency. The DENTAPORT 303 is further equipped with the very powerful BPR Swiss patent-pending suction system (220 l/min!) and a three-way syringe. Activating the complete standard unit only requires plugging in the air connection.
