Equipment Re-start & Maintenance Information

In the event your surgery has closed due to COVID-19 we have, in consultation with our suppliers, put together this handy guide on how to prepare and protect your equipment in the best possible way.

Below you will find:

  • Information on re-starting equipment after a long shut-down
  • Maintenance documents
  • Cleaning protocols

for our Equipment Brands supplied into the Australian market.

If you have any questions, or concerns, please email us and one of our Specialists will be in contact as soon as they can.

hygiene-people
[wpanchor id="carestream"]

Carestream

Carestream service engineers recommend that Carestream X-ray units need preparing following longer than 2-3 weeks of non-use.

Extraoral OPG & CBCT Tube Seasoning Procedure

After 2 or 3 weeks of non-use.

  • 3 exposures at 60 kV, 2 mA. Wait 10 minutes.
  • 1 exposure at 60 kV, 6.3 mA.
  • 2 exposures at 60 kV, 15 mA. Wait 10 minutes.
  • 1 exposure at 60 kV, 15 mA.
  • 1 exposure at 70 kV, 6.3 mA.
  • 1 exposure at 70 kV, 15 mA. Wait 10 minutes.
  • 1 exposure at 70 kV, 10 mA.
  • 1 exposure at 80 kV, 10 mA.
  • 1 exposure at 90 kV, 10 mA.

CS 2100 - Tube Seasoning

Performing the Tube Seasoning
This procedure allows for a progressive warm-up of the X-ray tube. It must be performed at unit installation and when replacing the tube head. It can also be performed, for instance after 3 weeks of equipment inactivity. It lasts around three minutes.

To perform the tube seasoning, follow these steps:

1. If the unit is switched OFF, switch it ON.

After the self-test is completed, I 02 is displayed. This message means that the seasoning process
must be started.

2 Press.

The display blinks. The sequence step number and the required exposure settings (kV, time) are displayed alternatively.

3 Stand behind the generator.

4. Launch an X-ray.

WARNING
Be careful not to be exposed to ionizing radiation

When the exposure is completed, the display blinks. The cooling error code (I 01) and the remaining time required before the next step are displayed alternatively.
When the cooling cycle is completed, the display blinks. The next step number and its exposure settings are displayed alternatively.

5 Repeat steps 3 and 4 until the end of the sequence. Several tube exposure cycles are performed.

Your system is ready.

IMPORTANT
If you receive error messages while you carry out the procedures, switch OFF and ON the unit and do all the procedures again.
If the error messages persist, see the “Corrective Maintenance” section for information on how to treat them.


>> CS 2100 Installation and Service Guide

CS 2200 - Tube Seasoning

Performing the Tube Seasoning
This procedure allows for a progressive warm-up of the X-ray tube. It must be performed at unit installation and when replacing the tube head. It can also be performed, for instance after 3 weeks of equipment inactivity. It lasts around three minutes.

To perform the tube seasoning, follow these steps:

1. If the unit is switched OFF, switch it ON.

After the self-test is completed, I 02 is displayed. This message means that the seasoning process
must be started.

2 Press.

The display blinks. The sequence step number and the required exposure settings (kV, time) are displayed alternatively.

3 Stand behind the generator.

4. Launch an X-ray.

WARNING
Be careful not to be exposed to ionizing radiation

 When the exposure is completed, the display blinks. The cooling error code (I 01) and the remaining time required before the next step are displayed alternatively. The red light of the cooling cycle is lit.

When the cooling cycle is completed, the display blinks. The next step number and its exposure settings are displayed alternatively.

5 Repeat steps 3 and 4 until the end of the sequence. Several tube exposure cycles are performed.

Your system is ready.

IMPORTANT
If you receive error messages while you carry out the procedures, switch OFF and ON the unit and do all the procedures again.
If the error messages persist, see the “Corrective Maintenance” section in the Installation and Service Guide for information on how to treat them.


>> CS 2200 Installation and Service Guide

[wpanchor id="sternweber"]

Stern Weber

Hygiene regulations and specific tasks to be performed to ensure the surgery is operationally efficient after a prolonged period of closure.

The main hygiene regulations

Before a prolonged period of closure it is good practice to perform a specific set of pre-closure tasks. If, for whatever reason, they have not already been performed, it is recommended that they be carried out, in any case, before re-opening the surgery.

As you are aware, the goal of surgery hygiene is to prevent the transmission of infectious diseases from one patient to another, to surgery/dental lab staff, and vice versa.

These suggestions aim to make this goal as achievable as possible by ensuring the workplace is, upon reopening (when a further set of tasks is performed), ready and efficient from day one.

The main goal of these few tasks is to empty the tubing, making sure no water is left inside dental units and circuits.
Doing so prevents the formation of biofilm in the internal circuits of the equipment, thus limiting any proliferation of bacteria.

What happens when a surgery or clinic has to be closed for a prolonged period?

Dental surgeries are considered biohazardous workplaces.

Numerous studies have demonstrated that dental unit water hoses/pipes are microbial agent (biofilm) reservoirs. The dental unit and its water system must therefore undergo several operations designed to reduce bacterial load, especially before prolonged periods of inactivity.

For these reasons, preventing contamination of the water in dental units and preventing any formation of biofilm in them is particularly important; this is equally true for autoclaves, which must therefore have their tanks emptied.

The goal is the same: to prevent proliferation of bacterial flora inside machines as much as possible, especially before prolonged periods of closure.



Basic tasks needed to ensure safe closure

10-Step Plan For Safeguarding Stern Weber Equipment

1 Where dental units have automatic, semi-automatic or manual sanitization/disinfection systems, carry out the respective cycles as indicated in the user's manual. If the dental unit is equipped with an independent spray feed tank (i.e. not connected to the mains water supply), it is recommended that it be emptied completely at the end of any cycle. https://www.sternweber.it/it/downloads/

2 Perform all the cleaning and maintenance tasks usually performed in the surgery at the end of the day; make sure all surfaces are disinfected properly. As for the dental unit, always use products that comply with the manufacturer's instructions and ensure they are used correctly as per the instructions in the user's manual.

It is essential to respect the contact time shown on the disinfectant package and, once this time has elapsed, remove the disinfectant with a clean damp cloth before drying. This minimises any potential on-surface aggression by the product, especially in the event of prolonged interruption of work, while ensuring effective sanitisation.

3 Clean the suction filters and, using the product recommended by the manufacturer, flush the suction circuit abundantly with lukewarm water by drawing from the “bucket” container.

Where there is an automatic cannulae flush system it is advisable - after completing the previous tasks - to empty the specific liquid from the tank, replace it with water and proceed with an additional flush cycle. Once the cycle is over, empty the tank.

4 Lastly, run dental unit surgical suction for at least 3 minutes to completely drain and dry the suction system.

5 Bring the patient chair to a position high enough to allow easy floor cleaning and assist discharge of the liquids in the internal dental unit tubing.

6 Switch off the osmosis system and drain it completely, if present. It is important to completely empty the storage tank and disinfectant tank (if the system is equipped with them).

7 Close the water shut-off tap for the individual surgery, if present:

  • Run all the dynamic instruments and syringes to drain the water in the pipes/hoses until there is none left.
  • Activate delivery of water to the cup until there is none left.
  • Activate delivery of water to the cuspidor bowl until there is none left. Then pour in the water-liquid solution for surgical suction, diluted as per the manufacturer's instructions; this is to reduce the bacterial load in the discharge pipes inside the dental unit.

8 Close the main water tap.

9 Drain the water system by opening all the basin taps in individual treatment rooms and/or ancillary rooms.

10 Turn off the ELECTRICAL panel for each individual room. It is advisable to leave the main surgery panel on to ensure operation of any other devices you wish to leave on (e.g. fridges for storage of compounds and medicines).


>> Stern Weber Equipment Re-start Manual

Autoclaves - procedure for closing down

1 Proceed so that the tanks are empty, clean and dry (whether they contain clean or dirty water).
To do this follow the instructions in the use and maintenance manual. https://www.sternweber.it/it/downloads/

2 Clean and lubricate the door seal.

3 Empty the ultrasound tank.

4 Empty the decontamination tank.

OTHER TASKS.

  1. Switch off the compressors control unit.
  2. Fully discharge the air compressors in the tanks.
  3. Switch off the suction devices control unit..

>> Stern Weber Equipment Re-start Manual

Tasks to be performed when reopening the clinic

How should I return water to the ducts and proceed with disinfection? We can answer this by applying the 5 minute rule.



Disinfection must cover the following aspects:

Bear in mind that the dental unit water system could be contaminated by oral bacteria or germs in the water (generally known as pseudomonas aeruginosa or legionella pneumophila).

The germ population, already held in check by the tasks performed prior to closure, can be reduced further. How? Let water flow from all taps for at least 5 minutes.

Let's now go into more detail and look at the sequence of tasks to be performed at the reopening phase after a prolonged period of closure.

SURGERY AND DENTAL UNITS

Turn on the main electrical panel in each surgery.

Switch on the compressors control unit.

Switch on the suction devices control unit.

Open the main water tap and individual surgery taps (if any).

If there is a centralised osmosis system, after turning it on and filling the tank with disinfectant (if it is part of the system), run water from the cuspidor bowls of all the units simultaneously for at least 5 minutes. Then proceed with reopening of the storage tank.

Run plenty of water into the basins.

Switch on each dental unit again and operate the cuspidor bowl and cup fountain, letting the water run abundantly.

Operate all dynamic instruments and syringes so fresh water arrives from the tubing.

Where the dental unit has automatic, semi-automatic or manual sanitization/disinfection systems, empty the tanks of their respective liquids, fill the tanks with fresh liquid and activate the processes as per the instructions in the use and maintenance manual.

AUTOCLAVES

Oil the hinges of the autoclave doors and fill the tank with clean water. If there is no water inlet treatment system, fill the tank with water having a conductivity of less than 15 μS/cm.

Check the door seal is not worn.

Perform a Vacuum Test cycle, an Elix Test cycle and a Bowie & Dick cycle, in compliance with local regulations.

Check that the expiry date (shown on the labels attached to the instrument pouches after the sterilization cycle is still valid.

INTRAORAL X-RAY UNITS

After prolonged non-use of the equipment, it is recommended that you carry out, on first start-up, a series of brief emissions (0.01-0.02 seconds) and, subsequently, take some X-rays with longer emission times of 0.1 second.

Doing so helps improve stabilisation of the X-ray tube before routine use.


>> Stern Weber Equipment Re-start Manual

[wpanchor id="durr"]

Dürr Dental

Practice break – what do I need to do? Checklist.

An increasing number of surgeries are having to shut down temporarily due to the spread of coronavirus. If surgeries do have to close, the following checklist is designed to provide you with all the information you will need to prepare the DÜRR DENTAL units you are using in the best possible way. The steps we recommend taking range from thorough cleaning and disinfection to depressurising compressors and checking settings on X-ray units. And if you have service or maintenance work pending or are waiting for a replacement unit, we can offer you a variety of options.

As a reliable partner DÜRR DENTAL will always remain at your side. Our absolute priority is to ensure that all products are in perfect working order when your surgery reopens.

Equipment

Suction System

  • Clean the suction system with MD 555 cleaner (note the specifications for concentration and reaction time, rinse with water after cleaning)
  • Disinfect the suction system with Orotol® plus (note the specifications for concentration and reaction time, DO NOT rinse with water after disinfecting)
  • Press the cleaning button on the spittoon valve and clean the yellow coarse filter (replace if necessary)
  • Change the yellow disposable filters on the hose manifolds
  • Switch off the water supply to the rinsing unit, drain the water
  • Clean the yellow filter on the suction unit inlet (wet suction systems only)
  • Change the amalgam collecting container on the amalgam separator (if you have an amalgam separator)
  • Remove all suction handpieces from the hose manifold to start up the suction unit. Run the suction unit for at least 30 minutes to dry the suction pipes.
  • Remove all suction handpieces from the suction hoses; clean and disinfect the handpieces according to the manufacturer information.

Compressor

  • Switch on the unit and wait until the cut-off pressure is reached
  • While the compressor unit is running, open the condensate drain valve on the membrane drying unit. Once all of the condensation water has escaped, close the condensate drain valve. Open the condensate drain valve. Once the start-up pressure has been reached, the compressor will switch on.
  • With the compressor switched on and the condensate drain valve open, wait until no more condensation water emerges
  • Close the condensate drain valve when no more air escapes
  • Disconnect all power from the unit
  • Disconnect the compressed air connection from the quick release coupling

Hygoclave

  • Leave the door ajar to relieve the door seal and prevent premature fatigue or any sticking
  • Disconnect the plug from the power outlet
  • Drain, clean and if necessary disinfect the internal fresh water and waste water containers
  • Shut off the water supply if using a water treatment system

Hygowater

  • Shut off the water supply
  • Turn off the tab
  • Release pressure from the unit

>> Dürr Practice Checklist

Diagnostic Imaging

Image plate scanner VistaScan

  • Cover the scanner with a hood to protect against dust
  • Monthly consistency check (in countries where a consistency check is mandatory)
  • If image plates have been kept for longer than a week, delete prior to use
  • Inspect image plates for damage. Guided automated checks can be carried out with VistaSoft Inspect AI (artificial intelligence).

X-ray Unit VistaPano

  • Monthly consistency check (in countries where a consistency check is mandatory
  • Move the units to the starting position (all the way down)
  • Clean and disinfect the surface as described in the operating instructions

X-ray Unit VistaVox

  • Monthly consistency check (in countries where a consistency check is mandatory
  • Move the units to the starting position (all the way down)
  • Clean and disinfect the surface as described in the operating instructions

X-ray generator VistaIntra

  • Move the units to the starting position (all the way down)
  • Clean and disinfect the surface as described in the operating instructions

Intraoral camera VistaCam

  • Clean and disinfect the surface as described in the operating instructions

Sensor VistaRay

  • Clean and disinfect the surface as described in the operating instructions

X-ray film development

  • Drain the chemicals and rinse through with water
  • Leave the unit to dry

>> Dürr Practice Checklist

Dental Care

MyLunos®

  • Properly clean and reprocess the handpiece body, supra- and perio-nozzle, according the instructions for reprocessing
  • Visual inspection of the O-rings and valves to check their condition, replace if necessary. Also observe the recommended intervals for changing the wearing parts.
  • Store of the handpiece body and the nozzles, following the packaged sterilisation, dust-protected in the sterile goods packaging (Observe storage time for the type of sterile packaging).

Vector®

Handpiece:

  • Cleaning and hygienic reprocessing of the Vector® handpieces and instruments according to the manual (Observe storage time for the type of sterile packaging)
  • Visual inspection of the O-rings and nozzle of the Vector® Paro handpiece, as well as the light guide of the Vector® Scaler handpiece. Change if necessary. Also observe the recommended intervals for changing the wearing parts.
  • Store of the handpiece body and the instruments, following the packaged sterilisation, dust-protected in the sterile goods packaging

Base unit:

  • Disinfect the outside surfaces and carry out cleaning and disinfection of all media-carrying lines
  • Remove the Vector® Fluid polish bag and handpiece and perform the RINSE function to rinse the base unit 1x with clear water
  • Afterwards, carry out the CLEAN process with Vector® Cleaner solution
  • Finish the process with a rinse with clean water
  • After completing the CLEAN process, fill the Vector® Paro base unit‘s water tank with the Vector® disinfectant solution and press the RINSE function once. This way, all media-carrying lines are filled with Vector® disinfectant solution.
  • After completing this process, empty the water tank, clean it and switch off the device
  • Please note the detailed description of all working steps in the operating instructions

>> Dürr Practice Checklist

[wpanchor id="durrcleaning"]


Dürr Dental – Cleaning Products

header_hygiene_neu_2

Dürr Cleaning Products stocked by Ivoclar

Code/LocationSAP CodeDescriptionUOMUsed for
DURR OROCUP704711SUCTION CLEANEREACHA cup for use with Orotol (sold without and chemicals)
DURR FD333716443SURFACE DISINFECTANT 1L1.0LAldehyde free, ready to use solution for fast-acting surface disinfection of invasive and non-invasive medical devices and medical furnishings in hospitals, private practices and laboratories.
DURR FD333716444SURFACE DISINFECTANT 2.5L2.5LAldehyde free, ready to use solution for fast-acting surface disinfection of invasive and non-invasive medical devices and medical furnishings in hospitals, private practices and laboratories.
DURR FD360716434CCF360C3500 CLEANING AND CARE OF VINYL UPHOLSTERYEACHCleaning Fluid for deep cleaning and care of synthetic leather surfaces.
DURR MD520716442IMPRESSION DISINFECTION 2.5L2.5LAldehyde-free ready to use solution for the similtaneous cleaning and care of spittoons in dental treatment units - with anti-microbial action
DURR MD555716441OROTOL CLEANER SPECIAL USE WEEKLY2.5LNon-foaming special cleaner for dental suction systems including drainage lines for regions with problematic tap water (e.g. hard water, water containing minerals with poor solubility, etc.) and for drainage lines with insufficient gradient.
OROTOL PLUS LIQ716448OROTOL PLUS SUCTION CLEANER 2.5L USE DAILY2.5LConcentrate for similtaneous disinfection, deodorisation, cleaning and care of dental suction systems, amalgam separators and spittoons.
Durr FD366 Sensitive Surfaces716447Durr FD366 Sensitive Surfaces 2.5LEachAldehyde-free , ready to use solution for fast-acting disinfection of sensitive surfaces on invasive and non-invasive medical devices in hospitals, private practices and laboratories.
Durr FD366 Sensitive Wipes737693Durr FD366 Sensitive Wipes / 100Tub of 100Practical disinfecting wipes for fast-acting disinfection of sensitive surfaces on invasive and non-invasive medical devices in hospitals, private practices and laboratories.
Durr FD366 Sensitive Wipes737694Durr FD366 Sensitive Wipes 4x100 CDF3664 x 100Practical disinfecting wipes for fast-acting disinfection of sensitive surfaces on invasive and non-invasive medical devices in hospitals, private practices and laboratories.



COVID-19 Exposure Times

Dürr Dental Cleaning Products Downloads (pdf)

[wpanchor id="wh"]

W&H Dental

Follow the step-by-step video guide through the hygiene workflow in your practice to interrupt the chain of infection… this ensures best practice reprocessing and your personal protection.

The video covers Used Instruments, Cleaning & Disinfection, Inspection & Lubrication, Packaging, Sterilisation and Storage.
